Custom Slave Pallet Dolly Supplier, Suppliers

Technical characteristics of products

It is suitable for loading standard 96 "× 125" pallet. and two AKE (60.4”*61.5”) It can be easily moved in any situation to meet the needs of various positions. The loading mode is loading on both sides.
The roller deck can work all day, and has good rainproof, moisture-proof and corrosion-resistant performance. Beautiful appearance, reasonable structure, high reliability, convenient maintenance and long service life.
The main frame is welded with the international standard 16 channel steel and 125 × 80 × 12 unequal angle steel,the welding adopts full welding, which is solid and durable.
All sides of the worktable are provided with fork slots, which are welded with 230 × 120 × 40 × 6mm C-shaped steel.
Two groups of movable baffles are installed on the outer side of the workbench, and six groups of movable baffles are installed on the inner side. The outer baffle is made of 20mm steel plate.
The drum adopts Φ 76 × 3mm seamless steel pipe (Galvanized), and the drum is evenly distributed on the working table.
After physical derusting (high-pressure sandblasting) of the whole vehicle, spray two coats of zinc rich epoxy antirust primer, and spray two coats of acrylic finish paint after the primer is dry, with strong adhesion and good antirust

Send Inquiry

Product Description

CHARACTER

✓

Solid rubber tyre for longer life.

✓

Loading: The trailer according to the pallet and container size, equipped with fixed limited guide plate on the two side, 3 sets of movable baffles at the both ends and the middle. The movable baffles at both ends are loaded with fall insurance. The boards can be loaded with P6P, P1P, PQA pallet, or LD1.2, LD2.2 container.

✓

Four fixed baffles in front and back reinforce the guiding function to prevent the goods from being jammed when the direction of loading is slightly improper.

✓

The tail is equipped with self-locking hook device to prevent the rear car from being decoupled so that the train can be smoothly connected.

✓

There are two rows of 28 galvanized roller drives, with a decorative walkway in the middle for easy operation.

✓

The mop has dual functions of multi-vehicle connection and brake.

✓

Designed with right and left fork parking spaces to facilitate the use of forklift truck towing card.

Frequently Asked Questions

What type of tires does this trailer use?

The trailer is equipped with solid rubber tyres, which are specifically chosen to ensure a longer service life and durability.

Which pallet and container sizes are compatible?

It is designed to accommodate P6P, P1P, and PQA pallets, as well as LD1.2 and LD2.2 containers.

How does the trailer prevent cargo from jamming during loading?

The unit features four fixed baffles at the front and back that reinforce the guiding function, ensuring smooth loading even if the direction is slightly improper.

Is there a safety mechanism for connecting multiple trailers?

Yes, the tail is equipped with a self-locking hook device that prevents decoupling, allowing for a secure and smooth train connection.

What are the characteristics of the roller system?

The trailer includes two rows of 28 galvanized roller drives and features a decorative walkway in the middle for easier operation.

Can this trailer be moved by a forklift?

Yes, it is designed with dedicated right and left fork parking spaces to facilitate easy towing by forklift trucks.
