Main Structure and Configuration
The CD5050GQS portable water truck is an advanced utility vehicle integrated with high-performance components including a specialized chassis, water tank, water supply system, hydraulic system, and electrical system.
Chassis System
Utilizing the Qingling QL10503HARY car chassis, the vehicle is powered by a robust 4JB1CN diesel engine (compliant with National Emission Standard V). The driver's cabin is designed for operator comfort, equipped with air conditioning and hydraulic power steering.
Clean Water Tank Features
✓
The water tank body is processed by advanced molding technology and joined via argon arc welding. The elliptical shape and smooth internal welding prevent debris accumulation.
✓
Equipped with electric heating and full insulation to ensure operational reliability in various climates.
✓
Large curved structures on front, rear, and side panels create a seamless inner cavity for easier cleaning and maintenance.
✓
Features an inclined drainage channel at the bottom for efficient leading drainage.
✓
Stability is maintained by two stainless steel anti-vibration plates and 6 floating supports to reduce vibration during transit.
✓
Equipped with dual 100mm inlet ports with filter screens and secure locking devices.
✓
Includes a ventilation port with filter to prevent vacuum effects during pump operation.
✓
Integrated inspection holes allow for easy disinfection and maintenance, protected by dust-proof and rain-proof sealing.
✓
A connecting rod floating ball level gauge is installed for precise monitoring and anti-freezing support.
✓
The circular arc bottom includes a sedimentation tank and stainless steel drainage ball valve for impurity discharge.
✓
The interior undergoes passivation treatment to prevent rust, while the exterior is finished with high-grade automotive paint.
Water Supply System
System Components: Composed of a water pump, water pipe box, pipeline, and specialized accessories.
• Water Pump: A stainless steel centrifugal pump driven by an oil motor, featuring mechanical seals and insulation measures.
• Pipeline & Safety: Includes stainless steel valves and pipes. A safety pressure regulating valve protects aircraft tanks from damage. A cab-mounted pressure gauge allows for real-time monitoring. The hose uses food-grade rubber cloth material (25mm diameter).
• Filling Joint: Complies with ISO450 standards for safe and reliable aircraft water replenishment.
Hydraulic & Electrical Systems
⚙
Hydraulic System: Consists of a power take-off (PTO), control mechanism, hydraulic oil tank, gear oil pump, hydraulic motor, and solenoid valves. The design prioritizes easy filter and valve maintenance.
⚡
Electrical System: Powered by a 12V DC system, including a control cabinet, battery, alarm lights, lighting fixtures, and safety switches.
Frequently Asked Questions (FAQ)
1. What kind of chassis and engine does the CD5050GQS use?
The truck uses a Qingling QL10503HARY chassis with a 4JB1CN diesel engine that meets National Emission Standard V.
2. Is the water tank protected against rust and corrosion?
Yes, the interior of the stainless steel tank undergoes welding spot removal and passivation treatment to ensure long-term rust resistance.
3. Can this water truck operate in cold environments?
Absolutely. The water tank features electric heating and insulation, and the water pump also includes heating and insulation measures.
4. Does the water supply system ensure aircraft safety?
Yes, it is equipped with a stainless steel safety pressure regulating valve to prevent any damage to the aircraft's water tank during filling.
5. How is the water level monitored by the operator?
The tank is equipped with a connecting rod floating ball level gauge, and there is a pressure gauge installed in the cab for easy observation.
6. What standards does the water filling joint comply with?
The filling joint complies with the international ISO450 standard, ensuring compatibility and safety for aircraft service.
